SMA Male RF Coaxial Termination Load – Straight Type, 1W Power

Brand Name : SIPU

Place of Origin : China

MOQ : 50

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Model Number : SMA-50JR

Certification : ISO9001, R0HS, CE

Delivery Time : 5-8 business days

Packaging Details : Carton

Price : ＄4.2-＄13.92, Price negotiable for large quantities

Supply Ability : 1000000 pcs/year

Characteristic impedance : 50Ω

Dielectric withstanding voltage : 1W

Product name : SMA Male RF Coaxial Termination Load – Straight Type, 1W Power

Gender : male

Type : Straight

Material : Brass

Plating : Gold

Contact Now

SMA Male RF Coaxial Termination Load – Straight Type, 1W Power

Product Overview

This coaxial termination load is a passive microwave component designed to absorb all incident RF energy and minimize signal reflection. It plays a critical role in optimizing system matching and ensuring stable circuit performance.

Applications:
Ideal for use in:
RF signal transmission system testing
Radio equipment
Electronic instrumentation
Microwave and communication devices

Product Features:

Connector Type: SMA male

Power Handling: 1W

Frequency Range: Wideband compatibility

Performance: High electrical performance with low VSWR

Durability: Excellent mechanical stability

Size: Compact design for space-constrained systems

This termination load is a reliable choice for high-frequency systems requiring consistent and loss-minimized signal termination.

Product Specifications

SMA Male RF Coaxial Termination Load – Straight Type, 1W Power

Important Technical Parameters

Electrical property

Temperature range

 -65～+125℃

Characteristic impedance

 50Ω

Frequency range

 DC-18GHz

Power

 1W

VSWR

Ordinary level:≤1.2

Precision grade:≤1.05

Mechanical property

Durability

500times

Materials and Surface Treatment

Center conductor

Brass, gold plating

Insulating medium

PTFE

Outer conductor

Brass, gold plating

Sealing ring

Silicon rubber

Product Image Gallery

SMA Male RF Coaxial Termination Load – Straight Type, 1W Power
